Room Thermostats
Room thermostats are control devices that are used to adjust the temperature in a space.
Each thermostat is designed to be connected to specific types of heating / cooling systems. Therefore, our future thermostat should state in its technical specifications that it is compatible with the system installed in the room.
Thermnostats are distinguished in analogue (mechanical) and digital (electronic). In addition, there are additional distinctions depending on functions and features, such as the Internet Thermostats, the Wireless Thermostats and the Programmable Thermostats, the PID or PWM Thermostats, the OPENTHERM Thermostats etc.
Thermostats of SALUS
SALUS Controls is a multinational company with a presence in a total of 80 countries and is considered one of the leading companies in the design and production of automation products specializing in the control of Heating / Cooling & Production of domestic hot water systems. It has a wide range of quality thermostats with modern optimization algorithms (PWM & TPI) for the quality control of the systems with great precision, as well as the unique Smart Home system which achieves real Energy Saving in the consumption of the building.
SALUS range includes thermostats for every application.
Refer to the following Thermostat Comparative Table below to select the appropriate thermostat.
Thermostat Comparative Table SALUS
SQ610 Quantum – Wifi Thermostat SALUS SALUS Smart Home
Flush-mounted, multi-functional thermostat with humidity sensor.
Suitable for use in systems with radiators or underfloor heating.
Optionally can be connected to Salus Smart Home and be controlled via the internet.
For more information and technical features see the thermostat at ANDRIANOS ESHOP.
SQ610RF Quantum – Wifi Thermostat SALUS Smart Home
Surface-mounted, multi-functional thermostat with humidity sensor.
Built-in Li-Ion battery & USB charging.
Suitable for use in systems with radiators or underfloor heating.
Optionally can be connected to Salus Smart Home and be controlled via the internet.
For more information and technical features see the thermostat at ANDRIANOS ESHOP.
HTR-RF(20) – Wireless room thermostat SALUS Smart Home
Ideal for users who appreciate the traditional dial with minimal intervention in the heating system.
Suitable for use in systems with radiators or underfloor heating.
Easy-to-use, with silent switching and TPI algorithm - a guarantee of precise temperature maintenance.
Optionally can be connected to Salus Smart Home and be controlled via the internet.
It can also works in offline mode (without Internet) as a simple, dial thermostat - with KL08RF wiring centre.
For more information and technical features see the thermostat at ANDRIANOS ESHOP.
HTRS-RF(30) – Wireless Digital Thermostat SALUS Smart Home
-thermostatis-salus-smart-home.png)
It is perfect for users who want to precisely control individual room temperature.
Suitable for use in systems with radiators or underfloor heating.
Easy-to-use, with a clear easy to read LCD display, with silent switching and TPI algorithm - a guarantee of precise temperature maintenance.
Optionally can be connected to Salus Smart Home and be controlled via the internet.
It can also works in offline mode (without Internet) as a simple, dial thermostat - with KL08RF wiring centre.
For more information and technical features see the thermostat at ANDRIANOS ESHOP.
HTRP-RF(50) – Wireless Digital Programmable Thermostat SALUS Smart Home
-thermostatis-smart-home.png)
It is perfect for users who want complete control over their underfloor heating system.
Easy-to-use, with a clear easy to read LCD display, with silent switching and TPI algorithm - a guarantee of precise temperature maintenance.
Optionally can be connected to Salus Smart Home and be controlled via the internet.
It can also works in offline mode (without Internet) as a simple, dial thermostat - with KL08RF wiring centre.
For more information and technical features see the thermostat at ANDRIANOS ESHOP.
VS10WRF/VS10BRF – Flush-mounted Thermostat SALUS Smart Home
Flush-mounted wireless thermostat that can work as programmable thermostats, no programmable thermostats, group controller or as a hot water timer.
Suitable for use in systems with radiators or underfloor heating.
Optionally can be connected to Salus Smart Home and be controlled via the internet.
It can also works in offline mode (without Internet) as a simple thermostat - with CO10RF coordinator.
Available in Black (BRF) and White (WRF).
For more information and technical features see the thermostat at ANDRIANOS ESHOP.
VS20WRF/VS20BRF – Thermostat SALUS Smart Home
Surface-mounted, wireless thermostat that can work as programmable thermostats, no programmable thermostats, group controller or as a hot water timer.
Suitable for use in systems with radiators or underfloor heating.
Optionally can be connected to Salus Smart Home and be controlled via the internet.
It can also works in offline mode (without Internet) as a simple thermostat - with CO10RF coordinator.
Available in Black (BRF) and White (WRF).
For more information and technical features see the thermostat at ANDRIANOS ESHOP.
FC600 – Fan Coil Controller SALUS Smart Home
Specific thermostat for controlling fan coil units.
Suitable for installation in hotels, offices and apartment buildings.
It allows you to reduce energy consumption while providing appropriate temperature and thermal comfort in the required spaces.
Optionally can be connected to Salus Smart Home and be controlled via the internet.
It can also operate autonomously (wired) as a local fan coil controller.
For more information and technical features see the thermostat at ANDRIANOS ESHOP.
TS600 – Wireless, surface-mounted, ZigBee temperature sensor SALUS Smart Home
Simple, wireless thermostat without LCD screen, is an economical solution for users who do not need local control.
Installation and configuration are carried out using the SALUS Smart Home application, the UGE600 universal gateway is also required for operation.
In Online mode it can communicate with devices such as: KL08RF wiring centre, mini TRV radiator head, RX10RF receiver, SR600 smart relay and SPE600 smart plug.
For more information and technical features see the thermostat at ANDRIANOS ESHOP.
RT310i – Internet Thermostat SALUS
Internet room thermostat that allows you to control your heating or cooling system from anywhere via your Smartphone, Tablet of PC.
Alternatively you can simply use the thermostat directly to control the temperature accurately.
For more information and technical features see the thermostat at ANDRIANOS ESHOP.
iT500 – Internet Thermostat SALUS
Internet room thermostat that allows you to control the temperature of your heating, cooling and domestic hot water through the free iT500 Plus mobile application.
Alternatively you can simply use the thermostat directly to control the temperature accurately.
For more information and technical features see the thermostat at ANDRIANOS ESHOP.
RT200 – Electronic Room Thermostat SALUS
A surface-mounted wired thermostat suitable for all heating applications.
For more information and technical features see the thermostat at ANDRIANOS ESHOP.
RT310 – Digital wired room thermostat SALUS
Digital room thermostat for wired control of heating devices.
Starts the heat source by closing the contacts. The thermostat is connected directly to the boiler.
It works by maintaining comfortable conditions in the room, in accordance with the constant temperature set by the user.
For more information and technical features see the thermostat at ANDRIANOS ESHOP.
RT510 – Digital Programmable Thermostat SALUS
Digital, programmable room thermostat for wired control of heating devices.
Starts the heat source by closing the contacts. The thermostat is connected directly to the boiler.
It works by maintaining comfortable room conditions in accordance with the work schedule or a constant temperature set by the user.
For more information and technical features see the thermostat at ANDRIANOS ESHOP.
RT520 – Digital programmable thermostat SALUS
Digital programmable thermostat for wired control of heating devices and is connected directly to the boiler.
Compatible with devices that support the OPENTHERM communication protocol.
Starting the heat source by closing contacts in a heating device equipped with an input for connecting the ON / OFF thermostat
Perfect solution for lanlords of real estate
It works by maintaining comfortable room conditions in accordance with the work schedule or a constant temperature set by the user.
For more information and technical features see the thermostat at ANDRIANOS ESHOP.
ERT20RF – Electronic Thermostat SALUS
An electronic, surface-mounted room thermostat that allows you to easily adjust the room temperature.
The thermostat is used to wirelessly control heating devices equipped with an ON / OFF thermostat input.
Suitable for remote control of the installation without a communication cable.
For more information and technical features see the thermostat at ANDRIANOS ESHOP.
RT310RF – Digital wireless room thermostat SALUS
Digital room thermostat to wirelessly control heating devices.
This thermostat includes two units, the receiver and the transmitter, which are connected to each other by radio frequencies.
It works by maintaining comfortable conditions in the room, in accordance with the constant temperature set by the user.
Recommended for controlling e.g. gas and oil boilers.
For more information and technical features see the thermostat at ANDRIANOS ESHOP.
RT510RF – Digital Programmable wireless Thermostat SALUS
Digital programmable thermostat is used for wireless control of heating devices, suitable for reliable remote control.
The thermostat offers energy savings of up to 30% compared to electromechanical and bimetallic thermostats.
It works by maintaining comfortable room conditions in accordance with the schedule work or a constant temperature set by the user.
Recommended for controlling e.g. gas and oil boilers.
For more information and technical features see the thermostat at ANDRIANOS ESHOP.
RT520RF – Digital thermostat SALUS
The digital programmable thermostat includes all the features of the previous RT series with a handy new suite of additional operational and efficiency functions, ideal for any property owner.
It is used for wireless control of heating devices and the receiver is connected to the boiler.
It works by maintaining comfortable room conditions in accordance with the work schedule or a constant temperature set by the user.
For more information and technical features see the thermostat at ANDRIANOS ESHOP.
HΤR230(20) – Dial room thermostat SALUS
-ilektronikos-thermostatis-salus.png)
Surface-mounted (or on a flush-box) room thermostat dedicated for surface heating / cooling control, characterized by high thermal inertia.
It is connected to the wiring centre, through which you can lower the set temperature on it, receiving a signal NSB (night temperature reduction) from the weekly thermostat.
For more information and technical features see the thermostat at ANDRIANOS ESHOP.
HTRS230(30) – Dial room thermostat SALUS
-thermostatis-psifiakos-salus.png)
Surface-mounted (or on a flush-box) room thermostat dedicated for surface heating / cooling control, characterized by high thermal inertia.
It is connected to the wiring centre.
The thermostat does not have the function of creating schedules - it lowers the set temperature via wiring centre after receiving the NSB signal from the weekly thermostat.
For more information and technical features see the thermostat at ANDRIANOS ESHOP.
HTRP230(50) – Wired Digital thermostat SALUS
-psifiakos-thermostatis-salus.png)
Surface-mounted (or on a flush-box) thermostat dedicated for surface heating / cooling control, characterized by high thermal inertia.
It is connected to the wiring centre.
For more information and technical features see the thermostat at ANDRIANOS ESHOP.
T105 – Digital Programmable Thermostat SALUS
The thermostat is used for wired control of heating devices (e.g. gas, oil boilers, heat pumps) or cooling devices.
It is connected directly to the heating device. Maintains comfortable room conditions in accordance with pre-programmed time and temperature settings.
The user should choose the right temperature for himself: comfort temperature (daytime) and economic temperature (nighttime).
For more information and technical features see the thermostat at ANDRIANOS ESHOP.
Τ105RF – Digital Programmable wireless Thermostat SALUS
The thermostat is used to wirelessly control heating devices (e.g. gas, oil boilers, heat pumps) or cooling devices.
It works by maintaining comfortable conditions in the room in accordance with the programmed settings.
The user should choose two temperature levels suitable for him: comfort temperature (daytime) and economic temperature (nighttime).
For more information and technical features see the thermostat at ANDRIANOS ESHOP.
ANDRIANOS, with experience in Energy Solutions for Heating and Cooling systems since 1994, has a complete set of Thermostats and Automations aiming at Energy Saving in all heating and cooling installations and fully cover the needs of professional and domestic installations. It also has Intelligent Management Systems to control all the basic functions of a home. These systems are commonly known as Smart Home systems.
ANDRIANOS tips for energy saving with the right choice and use of thermostats
The room thermostat is one of the most important factors in Energy Saving in Heating systems.
- It is recommended to set it to 22οC, aswe achieve Energy Savings of about 7%, for every 1οC that we reduce the temperature.
- It is recommended to replace the old thermostat with a new one, which has an algorithm (PID / PWM), so that it understands at all times not only what the room temperature is (like a conventional ON / OFF thermostat), but also how fast it changes (goes up or goes down), thus keeping the room temperature constant.
- It is also recommended to install thermostats or thermostatic radiator valves in each separate room, to achieve autonomy and the ideal temperature in each room, and not just one thermostat per apartment.
General information on thermostats & remote control systems
Categories of Room Thermostats
Analog and Digital thermostats
Thermostats are divided into analog (mechanical) and digital (electronic). ANDRIANOS has a complete range of space thermostats by SALUS that cover the needs of modern heating and air conditioning installations.
Analogue Room Thermostat Digital Room Thermostat
Analogue Thermostats SALUS:
See all analogue thermostats at ESHOP
Digital Thermostats SALUS:
See all digital thermostats at ESHOP
Internet room thermostats (Wifi thermostats)
The rapid development of technology and the need for extra savings has led companies to create modern thermostats systems with increased communication and control capabilities.
Wifi Thermostat Salus IT500
The internet thermostats (wifi thermostats) give the option of remote parameterization via the internet in comparison with conventional thermostats. This has the ability to control and adjust the heating and air conditioning system from the PC, Tablet, and Smartphone.
Wifi Thermostats SALUS:
Thermostats SALUS Smart Home:
See all Smart Home Thermostats at ESHOP
Wired or Wireless Communication - Thermostats with battery or wired with 230V
Room Thermostats, depending on how they are connected to the heat generating system (eg Boiler or Heat Pump), are distinguished in wireless and wired.
The wireless thermostats are communicating with the boiler via a wireless receiver that is installed in the boiler room and communicates wirelessly with the room thermostat installed in the building. In contrast, wired thermostats communicate via cable with the heat source.
Another distinction is the power supply of the thermostat, ie if it takes batteries or 230V power supply.
Wireless Thermostats SALUS:
See all wireless thermostats at ESHOP
Wired Thermostats SALUS:
See all wired thermostats at ESHOP
Thermostats SALUS with batteries:
See all thermostats with batteries at ESHOP
Thermostats SALUS with 230V power supply:
See all thermostats with 230V power supply at ESHOP
Room Thermostat Scheduling
An interesting function of the thermostats is the possibility of scheduling. Thermostats that have a time schedule can set a different room temperature according to a time schedule entered by the user.
With a chronothermostat, timing is possible in such a way that on the day, for example, the room has a temperature of 21 ° C and at night or the hours we are absent, 18 ° C. Changing the desired temperature is automatically done according to the program set by the user.
Wireless Chronothermostat Salus RT510RF
Advantages of scheduling:
- The room always has the desired temperature (eg in the morning we wake up) and is always maintained according to our needs.
- The heating system works more economically.
See all scheduling thermostats at ESHOP
Thermostats Self-learning (PID, PWM, ITLC, TPI)
The PID or PWM function of the most modern thermostats concerns the ability of the thermostat to perceive at any time not only the temperature of the room (such as a conventional ON / OFF thermostat), but also how quickly it changes (goes up or down) , thus maintaining the room temperature, constant.
The PID or PWM function of the most modern thermostats refers to the thermostat's ability to perceive at any moment not only the temperature of the room (such as a conventional ON / OFF thermostat) but also how quickly it changes (rises or goes down) , thus maintaining the room temperature stable.
Operation: PID thermostats are equipped with a microprocessor which:
i. It compares the desired temperature and the current one at regular intervals
ii. It records how quickly the deviation between the desired and the current temperature changes
iii. It foresees future deviations
Result: Through the above analysis, the thermostat selects the operation of the heating system in such a way that it reaches and maintains the desired temperature with the fewest possible fluctuations.
PiD control thermostats can achieve excellent comfort conditions since the temperature is constant but also economical because the space does not heat up more than you need.
The operation of the conventional thermostat (Hysteresis) and self-learnig thermostat (TPI&PWM) for the desired temperature
PiD control thermostats can and achieve excellent comfort conditions since the temperature is constant but also economical because the space does not heat up more than you need.
PiD control thermostat installation is indicated in underfloor heating installations (where the inertia of the heating system is high) and drastically improves the time delay of the temperature relative to the value set in the thermostat.
However this does not mean that the PiD or PWM thermostats are not the optimal choice for all heating installations, because thanks to "smart operation" they offer increased thermal comfort and energy saving. Learn more here
See all Self-learing thermostats at ESHOP
Thermostats OPENTHERM
OpenTherm (OT) is a standard communications protocol used in central heating systems for the communication between a central heating boiler and room thermostats, with the connection made from point to point or from multiple points to one point. As a standard, OpenTherm is independent of any single manufacturer. However, OpenTherm controllers and boilers do not in fact always work properly together. The OpenTherm standard comprises a number of optional features and some devices may include manufacturer-specific features. The presence or absence of such features may impair compatibility with other OpenTherm devices. We recommend if you are replacing your boiler, you research OpenTherm boilers well before purchase.
The communication is two-way between transmitter and receiver and it is possible to transfer various information such as machine status report, error reports and others, but the most common command is to control the operating temperature of the heat source.
The control is constantly controlled by the thermostat to change the temperature of the heat source accordingly, ensuring greater energy efficiency and savings.
In addition, the control via OpenTherm allows smoother control of its operation by adjusting the combustion and not just on - off, allowing the burner to operate close to the condensing temperature for longer, ensuring more economical operation.
The physical implementation of OpenTherm is done by 2 simple cables allowing the use of existing infrastructure. The only limitation is the maximum wiring length which is 50m and for a maximum resistance of 5 ohm per cable. The OT supports intelligent power supply and can support power of 35 mW (low), 136 mW (mid) or 255 mW (high) depending on the loads required to power such as backlight displays or motors. OT supports two standards, Opentherm Plus (OT +) and Opentherm lite (OT-), and deals with the signal configuration and commands supported by each.
OpenTherm Thermostats SALUS:
Central & Remote Control Systems
- Smart Home -
Modern centralized & remote control systems enable complete control of the heating and air conditioning system, even remotely, via the relevant web page or application on the smartphone and tablet. Those systems are usualy mentioned as Smart Home Systems.
The innovation of these systems lies in the fact that, in addition to heating and air conditioning, they can also control any electrical appliance or electrical system.
There is complete control of lights, electric shutters, garage doors, stand-alone air conditioners, electrical appliances.
In addition, Smart Home system include consumption meters to measure energy consumption, which, with proper analysis and corrective movements, offer extra savings.
Finally, it is noted that the individual Smart House systems, as well as the overall operation of the systems, are constantly evolving to control more and more points and functions in a modern home.
SALUS Smart Home System
What makes SALUS Smart Home system different from other systems is the way the products interact with each other. The communication is done by creating One Touch rules, which are a functional feature that allows the system to be extensively designed to meet your every need and desire and communicate with the products through the UGE600 gateway and the application (App). They allow you to create your own scenarios during the day based on your own desires. Such rules are a function of the application that allows you to customize the system to your needs and design the perfect day for you.
If the user has installed the SALUS Smart Home system in many places or properties, then he can quickly see what happens in each process by sliding the photos of the devices of each space from the screen of the control unit.
Remote control for Smart Home with the application for smart phone, tablet ή PC.
With free Salus Smart Home Application we control all the important functions of the building in the most modern, efficient and smart way through the mobile phone, tablet or computer. Application is available in 16 languages.
Download the application of Salus Smart Home for iOS & Android Smartphone.
Log in through your browser or see the demo via browser.
Login to your SALUS account via browser
See more information about Smart Home SALUS
Watts Vision Smart Home System
The Watts Vision system has a central control unit which communicates with the thermostats and the thermostatic radiator valves of each room. In addition, it has smartplugs for controlling electrical appliances and measuring electrical consumption.
The system is available with free apps (iOS, Android) for full control over cell phones and Tablet.
